Airtac BSC Clamp Cylinder BSC50X100S
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Compact Clamping Cylinder BSC50X100S Technical Details
- Model: BSC50X100S
- Type: Double-acting compact clamping cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Rubber buffer + adjustable cushion screw
- Mounting style: Basic type (ISO 15552 standard flange optional)
- Port size: M5x0.8 (standard), G1/8 optional
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 3.2 kg ±5%
- Dimensions (L×W×H): 200mm × 60mm × 60mm (extended length: 300mm)
- Piston speed: 50–800 mm/s
- Protection class: IP54 (standard)
High-precision clamping cylinder featuring space-saving design with integrated mounting grooves and anti-rotation mechanism. The dual piston seal structure ensures consistent gripping force even under side load conditions. Pre-lubricated for maintenance-free operation with 1 million cycle durability rating.
- Automated fixture systems in CNC machining centers
- Workpiece positioning in robotic welding cells
- Pallet clamping in assembly automation
- Precision mold holding devices
- Packaging machine product retention systems
Installation guidance: For optimal performance, maintain 0.3-0.5mm clearance between clamp arm and cylinder body.
Use locknuts (not included) on both ends of mounting bolts to prevent loosening from vibration.
Lubricate guide shafts every 5,000 cycles with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | BSC50X100S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | 100mm |
| Static Holding Force | 1400N |
