Airtac BSC Clamp Cylinder BSC50X125
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X125 Technical Specifications
- Model: BSC50X125
- Type: Double-acting clamp cylinder with mechanical lock
- Bore size: Ø50 mm
- Stroke: 125 mm
- Operating pressure: 0.05–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting: Standard ISO 15552 front flange (MF1) with rear foot mounts
- Port size: PT1/4 (M12×1.25 optional)
- Piston rod thread: M16×1.5
- Material:
- Tube: Hard anodized aluminum alloy
- End caps: Die-cast aluminum
- Piston rod: Chrome-plated carbon steel
- Seal material: NBR (Nitrile rubber)
- Weight: 2.8 kg (without accessories)
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (at mid-stroke position)
- Locking force: 1,200 N (at 0.5 MPa)
- Repeat positioning accuracy: ±0.5 mm
High-rigidity clamping cylinder featuring a unique wedge-lock mechanism that maintains holding force even during power loss. The dual piston design provides enhanced gripping stability with 30% higher clamping force compared to standard cylinders. Integrated shock absorbers minimize end-impact vibration, making it ideal for precision positioning tasks.
- CNC machine tool fixture clamping
- Automated welding jig positioning
- Robotic assembly line workholding
- Press brake tool securing systems
- High-vibration environment locking mechanisms
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Maintain 0.3-0.5 MPa holding pressure for optimal lock engagement.
Avoid side loads exceeding 50N during operation.
- Maximum side load capacity: 150 N
- Lock release pressure: ≥0.15 MPa
- Response time (lock engagement): ≤0.3 sec
- Service life: 5,000 km (piston rod travel distance)
| Property | Property Value |
|---|---|
| sku | BSC50X125 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | 125mm |
| Static Holding Force | 1400N |
