Airtac BSC Clamp Cylinder BSC50X160S
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X160S Technical Specifications
- Model: BSC50X160S
- Type: Compact double-acting clamp cylinder
- Bore size: Ø50 mm
- Stroke: 160 mm
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning type: Fixed rubber buffer + adjustable air cushion
- Mounting style: Basic foot mounting (ISO 15552 compatible)
- Port size: M5x0.8 (G1/8 adaptor included)
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal material: NBR (nitrile rubber)
- Weight: 2.8 kg ±3%
- Dimensions (L×W×H):
- Extended length: 322 mm
- Retracted length: 162 mm
- Body width: 60 mm
- Mounting base height: 85 mm
- Lubrication: Pre-lubricated (DOP mist compatible)
- Protection class: IP65 (standard wiper seal)
High-precision industrial clamp cylinder featuring space-saving design with integrated clamping mechanism. The dual cushioning system minimizes impact noise while maintaining positioning accuracy (±0.5mm repeatability). Enhanced rod bearing structure supports 20% higher side load capacity compared to standard cylinders. Requires filtered air (5-40μm) with 1μm filtration for optimal seal life.
- Automated fixture clamping in CNC machining centers
- Workpiece positioning in robotic welding systems
- Press-fit assembly operations in automotive production
- Pallet locking mechanisms in material handling
- Precision mold clamping for injection molding
Installation guidelines:
Align clamping axis within 0.2mm perpendicular tolerance.
Use anti-vibration washers for high-cycle applications (>500,000 cycles).
Lubricate every 5 million cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | BSC50X160S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | 160mm |
| Static Holding Force | 1400N |
