Airtac BSC Clamp Cylinder BSC50X175S
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X175S Technical Details
- Model: BSC50X175S
- Type: Double-acting clamp cylinder
- Bore size: Ø50 mm
- Stroke: 175 mm
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Standard flange mounting (MF1)
- Port size: M5x0.8 (G1/8 equivalent)
- Piston rod thread: M16x1.5
- Temperature range: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy with hard anodization
- End covers: Die-cast aluminum
- Piston rod: Chrome-plated steel
- Seals: NBR (Nitrile rubber)
- Protection rating: IP54 (standard), IP67 optional
- Weight: 2.8 kg ±3%
- Dimensions (L×W×H): 300mm × 60mm × 60mm (including mounting hardware)
High-precision clamping cylinder featuring wear-resistant construction and dual anti-rotation guides for stable gripping operations. The T-slot mounting surface (ISO 21287 compliant) enables flexible fixture integration. Enhanced rod bearing design supports side load capacity up to 15% of maximum thrust.
- CNC machine tool workpiece clamping
- Automated welding fixture positioning
- Palletizing robot end-effector tooling
- Injection molding machine mold locking
- Automotive assembly line jig systems
Installation guidelines:
Maintain 0.5-1mm clearance between clamp arm and cylinder body during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation. Perform maintenance
every 5,000km stroke or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | BSC50X175S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | 175mm |
| Static Holding Force | 1400N |
