Airtac BSC Clamp Cylinder BSC50X200S
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X200S Technical Specifications
- Model: BSC50X200S
- Type: Double-acting compact clamp cylinder
- Bore size: Ø50mm
- Stroke: 200mm (adjustable cushion)
- Operating pressure: 0.05-1.0 MPa
- Max thrust: 196N @0.63MPa
- Port size: M5x0.8 (G1/8 adaptor included)
- Piston material: Aluminum alloy hard anodized
- Rod material: Chrome-plated carbon steel
- Seals: NBR+PU hybrid seals
- Temperature range: -20℃ to 80℃
- Weight: 2.85kg ±3%
- Dimensions: 235mm(L) × 50mm(Bore) × 68mm(H)
- Mounting: Standard ISO 15552 front flange
- Cushioning: Adjustable air cushion (both ends)
- Repeat accuracy: ±0.5mm
High-precision industrial cylinder featuring integrated clamping mechanism with 3-stage position locking. The nickel-plated piston rod and dual-layer sealing system ensure reliable operation in high humidity environments. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Fixture positioning in CNC machining centers
- Workpiece clamping in automotive welding lines
- Precision alignment systems for semiconductor FOUP handling
- Mold locking in injection molding machines
- Automated pallet securing systems
Installation note:
Maintain 0.5-1mm clearance between clamp jaws and workpiece surface.
Lubricate guide rails monthly with EP2 grease. Avoid side-load exceeding 30N.
| Property | Property Value |
|---|---|
| sku | BSC50X200S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | <200mm> |
| Static Holding Force | 1400N |
