Airtac BSC Clamp Cylinder BSC50X225
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamping Cylinder BSC50X225 Technical Specifications
- Model: BSC50X225
- Type: Double-acting clamping cylinder
- Bore size: Ø50 mm
- Stroke: 225 mm
- Operating pressure: 0.1-0.9 MPa
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Cylinder tube: Hard anodized aluminum alloy
- Seal material: NBR/PU hybrid seals
- Temperature range: -20℃ to +80℃
- Cushioning: Adjustable pneumatic cushioning (both ends)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Mounting style: Basic type (optional flange/feet mounting)
- Weight: 2.65 kg ±3%
- Dimensions (L×W×H):
- Extended length: 465 mm
- Retracted length: 240 mm
- Body diameter: Ø50 mm
- Mounting hole spacing: 60 mm (ISO 15552 standard)
- Protection class: IP54 (standard)
The BSC50X225 clamping cylinder features a dual-piston design with enhanced lateral rigidity, delivering 30% higher clamping force compared to standard cylinders. Its precision-ground guide rods and integrated anti-rotation mechanism ensure stable operation under heavy side loads. The cylinder incorporates wear-compensating seals and a scratch-resistant rod coating for extended service life in particulate-heavy environments.
- CNC machine tool fixture systems
- Automotive welding jig positioning
- Die-casting mold locking mechanisms
- Robotic material handling end effectors
- Semiconductor wafer handling equipment
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Use alignment jigs for multi-cylinder setups.
For optimal performance, install a 5μm filter regulator and lubricator (FRL) unit upstream.
Pre-lubricate through air ports before initial operation.
Critical note:
Avoid side load exceeding 150N. When used in vertical orientation,
install mechanical locks for fail-safe operation. Maximum allowable
piston speed: 750 mm/s. Cycle rate not to exceed 80% of calculated duty cycle.
| Property | Property Value |
|---|---|
| sku | BSC50X225 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | 225mm |
| Static Holding Force | 1400N |
