Airtac BSC Clamp Cylinder BSC50X25
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X25 Technical Specifications
- Model: BSC50X25
- Type: Double-acting clamp cylinder
- Bore size: Ø50 mm
- Stroke: 25 mm
- Operating pressure: 0.15–0.8 MPa
- Max thrust: 1,570 N (at 0.6 MPa)
- Piston rod: Ø20mm chromium-plated steel
- Buffer type: Adjustable cushioning
- Mounting style: Standard flange (ISO 15552 compatible)
- Port size: M5x0.8 (dual ports on both ends)
- Material: Aluminum alloy barrel, stainless steel end caps
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 2.1 kg ±3%
- Dimensions: 150mm(L) × 50mm(W) × 50mm(H) (retracted state)
- Rod thread: M10x1.25 (external)
- Protection rating: IP54 (standard)
The BSC50X25 clamp cylinder features a reinforced structure with dual anti-rotation guides, delivering 20% higher gripping force compared to standard cylinders. Its compact design integrates T-slot mounting grooves for flexible installation in space-constrained environments. The chrome-plated piston rod resists scoring while maintaining smooth operation through 1 million cycles.
- Workpiece fixturing in CNC machining centers
- Pallet locking systems in automated warehouses
- Tool changing mechanisms for robotic arms
- Press-fit assembly operations
- Mold clamping in injection molding machines
Installation note:
Maintain 0.5mm minimum clearance between clamp jaws and cylinder body.
Lubricate with ISO VG32 hydraulic oil during maintenance cycles.
Avoid side loads exceeding 50N to prevent guide rail deformation.
| Property | Property Value |
|---|---|
| sku | BSC50X25 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | <25 mm> |
| Static Holding Force | 1400N |
