Airtac BSC Clamp Cylinder BSC50X300S
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC50X300S Clamp Cylinder Technical Specifications
- Model: BSC50X300S
- Type: Compact series clamp cylinder (ISO 6432 compliant)
- Bore size: 50mm
- Stroke: 300mm
- Operation: Double-acting
- Mounting style: Front/rear flange & foot mounting
- Port size: M5x0.8 (standard) / G1/8 optional
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable rubber buffer
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Ambient temperature: -20℃ to +80℃
- Weight: 2.65kg ±3%
- Dimensions:
- Extended length: 480mm
- Retracted length: 180mm
- Body diameter: 50mm
- Mounting hole spacing: 36mm (vertical) × 25mm (horizontal)
- Protection class: IP54 (standard)
- Lubrication: Pre-lubricated (DOP-free grease)
High-rigidity clamp cylinder featuring space-saving design with integrated mounting grooves. The dual piston guide structure ensures precise linear motion and anti-rotation performance. Optimized for high cycle applications (up to 5 cycles/sec) with wear-resistant rod seals. Includes magnetic piston for sensor compatibility.
- PCB handling robots - component positioning
- Automotive welding fixtures - part clamping
- CNC machine tool - tool changer mechanisms
- Pharmaceutical packaging - vertical pressurization
- Solar panel assembly - laminator compression
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting.
Use locknuts with 12-15Nm torque for flange fixation.
For vertical mounting, install air vent at upper port.
| Property | Property Value |
|---|---|
| sku | BSC50X300S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | 300mm |
| Static Holding Force | 1400N |
