Airtac BSC Clamp Cylinder BSC50X400
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X400 Technical Specifications
- Model: BSC50X400
- Type: Double-acting clamp cylinder
- Bore size: Ø50 mm
- Stroke: 400 mm
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard square flange (ISO 15552 compatible)
- Port size: G1/8 (NPT1/8 optional)
- Operating temperature: -20℃ to 80℃
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: High-wear NBR rubber
- Weight: 5.8 kg ±2%
- Dimensions: 580mm(L) × 80mm(W) × 80mm(H)
- Rod thread: M16×1.5
- Max thrust: 1570N @0.63MPa
- Protection rating: IP54 (standard), IP67 (optional)
High-rigidity clamp cylinder with integrated mounting structure, featuring enhanced side load capacity through precision-guided piston design. The hardened piston rod and triple-lip seals ensure 3,000km+ service life under continuous operation. Includes magnetic piston version (BSC50X400-M) for position sensing.
- Fixture clamping in CNC machining centers
- Workpiece positioning in automotive welding lines
- Mold locking mechanisms in injection molding
- Heavy part retention in material handling systems
- Precision alignment in semiconductor manufacturing
Installation guidelines:
Apply anti-vibration washers when mounting on dynamic platforms.
Maintain 0.5-1mm clearance between clamp arm and cylinder body
to prevent side load damage. Lubricate with ISO VG32 hydraulic oil
during initial installation.
| Property | Property Value |
|---|---|
| sku | BSC50X400 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | <400mm> |
| Static Holding Force | 1400N |
