Airtac BSC Clamp Cylinder BSC50X400S
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X400S Technical Specifications
- Model: BSC50X400S
- Type: Double-acting clamp cylinder with mechanical lock
- Bore size: Ø50 mm
- Stroke: 400 mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable rubber buffer + air cushion
- Mounting style: Standard foot mounting (ISO 15552 compatible)
- Rod thread: M16×1.5
- Port size: G1/8 (NPT1/8 optional)
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: NBR seals (FKM available on request)
- Temperature range: -20℃ to 80℃
- Weight: 4.8 kg (dry, without accessories)
- Dimensions:
- Extended length: 640 mm
- Retracted length: 240 mm
- Body diameter: Ø62 mm
- Mounting base: 90×40 mm
- Max thrust: 785 N @ 0.63 MPa
- Repeat accuracy: ±0.5 mm
The BSC50X400S clamp cylinder combines precision linear motion with a fail-safe mechanical locking mechanism, designed for high-load holding applications. Features dual cushioning system for smooth end-of-stroke deceleration and integrated mounting grooves for sensor installation. Corrosion-resistant construction with IP54 protection rating ensures reliable operation in industrial environments.
- Fixture clamping in CNC machining centers
- Workpiece positioning in automotive assembly lines
- Mold locking in injection molding machines
- Heavy load stabilization in material handling systems
- Precision alignment in semiconductor manufacturing
Installation guidelines:
Maintain 0.5-1mm clearance between clamp arm and workpiece surface during initial positioning.
Lubricate with ISO VG32 hydraulic oil for initial operation. Perform lock mechanism inspection every 500,000 cycles.
- Built-in mechanical lock sustains position during power loss
- Dual guide rod design prevents rotation under side loads
- Optional magnetic piston for position feedback (add "-M" to model)
- Anti-vibration pads integrated in mounting base
| Property | Property Value |
|---|---|
| sku | BSC50X400S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | <400mm> |
| Static Holding Force | 1400N |
