Airtac BSC Clamp Cylinder BSC50X450
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X450 Technical Specifications
- Model: BSC50X450
- Type: Double-acting clamp cylinder with reinforced structure
- Bore size: Ø50mm (±0.1mm honed tolerance)
- Stroke: 450mm (Max. stroke for BSC50 series: 500mm)
- Operating pressure: 0.1–0.9 MPa (1–9 bar)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Front flange (MF1) / Rear flange (MF2) standard
- Piston rod material: Chrome-plated SCM435 steel
- Tube material: Aluminum alloy (A6063-T5 anodized)
- Seal material: NBR (Nitrile) standard, optional PU/Viton
- Temperature range: -20℃ to 80℃ (NBR seals)
- Port size: M5x0.8 (G1/8 adapter available)
- Weight: 2.65kg (excluding mounting accessories)
- Dimensions: 550mm(L) × 63mm(W) × 63mm(H) (Stroke length included)
- Rod thread: M12x1.75 (Male thread both ends)
- Max. lateral load: 120N at full extension
- ISO standard: 15552 compliant design
The BSC50X450 clamp cylinder features a rigid square body design with 4-position mounting holes for stable clamping applications. Its anti-rotation mechanism maintains precise alignment during high moment load operations. The cylinder incorporates wear-resistant guide bands and a dual-seal piston design, achieving over 5,000km service life at rated conditions. Requires 40μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Plastic injection molding machine ejector systems
- Automated welding fixture positioning
- CNC machine tool workpiece clamping
- Automotive assembly line pallet locking
- Glass manufacturing conveyor stoppers
Installation guidelines:
Apply Loctite 243 to mounting screws (8.8 grade or higher).
Maintain 0.5mm minimum clearance between clamp surfaces.
Lubricate with ISO VG32 turbine oil during maintenance cycles.
| Property | Property Value |
|---|---|
| sku | BSC50X450 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | 450mm |
| Static Holding Force | 1400N |
