Airtac BSC Clamp Cylinder BSC50X450S
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X450S Technical Details
- Model: BSC50X450S
- Series: BSC (Clamp Cylinder Series)
- Bore size: 50mm
- Stroke: 450mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Buffer type: Adjustable hydraulic cushion (both ends)
- Piston rod thread: M16×1.5
- Port size: G1/8 (ISO228 standard)
- Seal material: Polyurethane (PU) & Nitrile rubber (NBR)
- Repeat positioning accuracy: ±0.5mm
- Max speed: 500mm/s
- Lateral load capacity: ≤15% of max thrust
- Weight: 6.8kg (with standard accessories)
- Dimensions: 625mm(L) × 102mm(W) × 102mm(H)
- Mounting type: Square flange (ISO/VDMA standard)
- Rod end type: Female thread + Hex nut
- Corrosion protection: Black anodized aluminum body
High-rigidity clamp cylinder designed for precision fixturing applications, featuring integrated mechanical locking mechanism that maintains position without continuous air supply. The dual piston design ensures 360° uniform clamping force distribution. Hard chrome-plated piston rod with wear-resistant guide bushings enables stable operation in high-moment load scenarios.
- CNC machine tool workpiece clamping systems
- Automated welding fixture positioning
- Press brake tool holding mechanisms
- Robotic arm end-effector locking
- Precision mold alignment in injection molding
Installation protocol:
Always align clamping surface perpendicular to workpiece axis (±0.5° tolerance).
Use torque wrench for flange bolts (recommended 22-25N·m). Maintain 0.5-1mm gap between
clamp jaw and cylinder body during initial positioning.
| Property | Property Value |
|---|---|
| sku | BSC50X450S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | 450mm |
| Static Holding Force | 1400N |
