Airtac BSC Clamp Cylinder BSC50X50
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Series Clamp Cylinder BSC50X50 Technical Details
- Model: BSC50X50
- Type: Double-acting compact clamp cylinder
- Bore size: Ø50 mm
- Stroke: 50 mm (customizable 25-300mm)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Ambient temperature: -20℃ to 80℃
- Buffer type: Adjustable rubber cushion
- Mounting style: Basic type (MF1) with multiple mounting options
- Rod material: Hard chrome-plated carbon steel
- Seal material: NBR/PU (optional FKM)
- Weight: 2.8 kg (without accessories)
- Dimensions:
- Body length: 165 mm
- Extended length: 215 mm (stroke 50mm)
- Mounting base: 50×50 mm square profile
- Rod end thread: M16×1.5
- ISO standard: 6432 (compact cylinder specifications)
- Protection rating: IP54 (standard), IP67 optional
High-rigidity clamping cylinder with integrated mounting grooves, optimized for precision fixturing applications. Features wear-resistant guide bushings and dual anti-rotation pins for stable gripping force transmission. Compatible with magnetic sensors (D-M9N series) for position feedback.
- CNC machine tool workpiece clamping
- Robotic welding fixture positioning
- Automated assembly line pallet locking
- Press tooling alignment systems
- Semiconductor wafer handling equipment
Installation guidelines:
Apply 2-3Nm torque for mounting bolts. Lubricate with ISO VG32 hydraulic oil
before initial operation. Maintain 0.3mm minimum clearance between clamp arm
and cylinder body during mechanical design.
- Max side load: 150N at full extension
- Repeat positioning accuracy: ±0.2mm
- Static holding force: 1,960N @0.5MPa
- Cycle life: 5,000km travel distance (NBR seals)
| Property | Property Value |
|---|---|
| sku | BSC50X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | <50mm> |
| Static Holding Force | 1400N |
