Airtac BSC Clamp Cylinder BSC50X500
2、Enables intermediate stroke locking at any position throughout the piston travel;
3、Incorporates a bi-directional locking system where clamping engagement remains effective independent of piston motion direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSC
AirTAC BSC Clamp Cylinder BSC50X500 Technical Specifications
- Model: BSC50X500
- Type: Double-acting clamp cylinder
- Bore size: Ø50 mm
- Stroke: 500 mm
- Operating pressure: 0.1–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: Standard MF1 flange (ISO 15552 compatible)
- Port size: G1/8 (NPT1/8 optional)
- Piston rod thread: M16×1.5
- Material:
- Cylinder tube: Aluminum alloy hard anodized
- End caps: Cast aluminum
- Piston rod: Chrome-plated steel (Cr-Mo)
- Seal material: NBR (Nitrile) standard / FKM (Viton) optional
- Weight: 5.8 kg (with rod)
- Dimensions:
- Extended length: 975 mm
- Retracted length: 475 mm
- Body width: 70 mm
- Mounting flange height: 110 mm
- Max thrust: 1,963 N @ 0.63 MPa
- Rod rotation: ±5° adjustable
- ISO standard: 15552 (formerly ISO 6431)
High-rigidity clamp cylinder designed for heavy-duty holding applications. Features precision ground rod with multi-layer sealing system and anti-vibration locking nuts. The dual cushion design minimizes end-impact noise (≤70 dB). Includes wear-resistant guide bands for smooth operation under side load conditions. Compatible with auto-switch sensors (slot width 16mm).
- Fixture clamping in CNC machining centers
- Press brake tool holding systems
- Automotive welding jig positioning
- Die casting machine mold locking
- Heavy component alignment in assembly lines
Maintenance note:
Relubricate every 500,000 cycles using ISO VG32 hydraulic oil.
Avoid angular misalignment exceeding 0.5° during installation.
For vertical mounting, use rod-down orientation to prevent seal wear.
| Property | Property Value |
|---|---|
| sku | BSC50X500 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | Bore Size: 50mm |
| Stroke | 500mm |
| Static Holding Force | 1400N |
