Airtac BSCD Clamp Cylinder BSCD100X1000
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD Series Clamping Cylinder BSCD100X1000 Technical Details
- Model: BSCD100X1000
- Bore size: 100mm
- Stroke: 1000mm
- Operation type: Double acting
- Working pressure: 0.05-1.0 MPa
- Cushion type: Adjustable rubber buffer + fixed cushion
- Mounting style: Standard MF1 (front flange)
- Port size: G3/8 (ISO standard)
- Piston speed: 50-800mm/s
- Ambient temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated steel (Cr-Mo)
- End caps: Extruded aluminum
- Seal material: NBR + PU combination
- Weight: 23.5kg ±2% (without accessories)
- Dimensions:
- Extended length: 1395mm
- Retracted length: 395mm
- Body diameter: 118mm (max OD)
- Mounting hole spacing: 160mm × 160mm
High-rigidity clamping cylinder with reinforced guide structure, designed for heavy-duty industrial applications requiring precise linear motion and vibration resistance. Features dual-layer sealing system with dust wiper, and corrosion-resistant surface treatment. Requires ISO VG32 hydraulic oil or equivalent lubrication.
- Automotive welding fixture systems
- Die-casting machine mold clamping
- Heavy material handling robots
- Press brake tool positioning
- Large CNC machine workpiece fixation
Installation guidelines:
Maximum allowable side load 850N. Requires perpendicularity tolerance ≤0.2mm/m.
Lubricate every 3,000km of cumulative stroke movement. Avoid lateral force during
mounting alignment using laser calibration tools.
| Property | Property Value |
|---|---|
| sku | BSCD100X1000 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
| Static Holding Force | 5500N |
