Airtac BSCD Clamp Cylinder BSCD100X1000S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X1000S Clamp Cylinder Specifications
- Model: BSCD100X1000S
- Type: Double-acting compact clamp cylinder
- Bore size: Ø100 mm
- Stroke: 1000 mm
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Basic type (no built-in mounts)
- Port size: G1/2 (ISO228 standard)
- Piston rod thread: M20×1.5
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 12.5 kg (without accessories)
- Dimensions: 1165mm(L) × 100mm(W) × 100mm(H)
- Protection rating: IP40 (dust protected)
- Magnetic switch compatibility: Pre-drilled slots for D-A93 series sensors
High-force clamp cylinder designed for heavy-duty positioning and pressing applications. Features precision honed tubing and double-seal construction for leak prevention. The extended 1000mm stroke version includes reinforced guide bearings to prevent piston deflection, with chrome-plated piston rod offering corrosion resistance in humid environments.
- Automotive welding fixture clamping
- Injection molding machine ejector systems
- Sheet metal press brake tooling
- Palletizing robot end-effectors
- Battery module compression testing
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm/m. Lubricate with ISO VG32 hydraulic oil
during initial setup. For full stroke operation, maintain air supply pressure above 0.3 MPa.
Allow 50mm clearance at both ends for cushion adjustment.
| Property | Property Value |
|---|---|
| sku | BSCD100X1000S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
| Static Holding Force | 5500N |
