Airtac BSCD Clamp Cylinder BSCD100X100S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X100S Clamp Cylinder Technical Specifications
- Model: BSCD100X100S
- Series: BSCD Compact Clamp Series
- Bore size: Ø100 mm
- Stroke: 100 mm
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Rubber buffer + adjustable cushioning
- Port size: G3/8 (ISO standard)
- Piston rod thread: M20×1.5
- Mounting type: Basic foot mounting (ISO 15552 compatible)
- Cylinder material: Aluminum alloy (hard anodized)
- Rod material: Chrome-plated carbon steel
- Seal material: NBR/PU hybrid seals
- Weight: 5.8 kg (with standard accessories)
- Dimensions:
- Body length: 298 mm
- Extended length: 398 mm (stroke included)
- Width: 120 mm (mounting base)
- Height: 125 mm (including rod end)
- Repeat accuracy: ±0.5 mm
- Max lateral load: 450 N
- ISO certification: 6431, VDMA 24562
High-precision clamping cylinder with space-saving design, featuring dual anti-rotation guides for enhanced stability during lateral force applications. The hardened piston rod and hybrid seals ensure 3,000 km+ service life under standard conditions. Integrated cushioning adjustment allows fine-tuning for 50-500 mm/s speed ranges.
- Fixture positioning in CNC machining centers
- Press-fit assembly of automotive components
- Pallet locking in automated warehouses
- Mold clamping for injection molding machines
- Workpiece retention in robotic welding cells
Installation guidelines:
Maintain perpendicular alignment between clamp axis and workpiece surface.
Lubricate with ISO VG32 hydraulic oil during initial installation.
Recommended maintenance interval: 5 million cycles or 12 months.
Critical note:
Avoid side impact loads exceeding 20% of maximum capacity.
Use filtered air (5-40 μm) with dew point -25℃ below ambient temperature.
| Property | Property Value |
|---|---|
| sku | BSCD100X100S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
| Static Holding Force | 5500N |
