Airtac BSCD Clamp Cylinder BSCD100X125S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD Clamp Cylinder BSCD100X125S Technical Specifications
- Model: BSCD100X125S
- Type: Double-acting clamp cylinder
- Bore size: Ø100 mm
- Stroke: 125 mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable pneumatic cushioning
- Mounting style: Front/rear flange mounting (ISO 15552 standard)
- Port size: G3/8 (M14x1.5 thread optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 3.8 kg (without accessories)
- Dimensions: 325mm(L) × 112mm(W) × 112mm(H) (at mid-stroke position)
- Rod thread: M20x1.5 (external)
- Max thrust: 706N @0.63MPa
- Piston speed: 50–800 mm/s
High-precision industrial clamp cylinder featuring wear-resistant chromium piston rod and dual anti-rotation guides. The T-slot mounting surface enables secure workpiece gripping with optional jaw attachments. Designed for 500,000+ cycle durability with <1mm positional repeat accuracy under 0.5MPa.
- CNC machine tool workpiece fixturing
- Robotic welding station positioning clamps
- Automotive component assembly presses
- Palletizing robot end-effector gripping
- Electronics PCB holding during SMT processes
Installation tip:
Maintain 0.5-1mm clearance between clamp jaws and cylinder body during mounting.
Use locknuts (not included) on rod threads for repeated adjustment. Lubricate with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | BSCD100X125S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
| Static Holding Force | 5500N |
