Airtac BSCD Clamp Cylinder BSCD100X150S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD Series Clamp Cylinder - BSCD100X150S Technical Details
- Model Code Breakdown: BSCD-100-X-150-S
(Series-Bore size-Extension rod-Stroke length-Special configuration) - Type: Double-acting clamp cylinder with mechanical lock
- Bore diameter: Ø100mm ±0.5mm tolerance
- Stroke length: 150mm (adjustable ±2mm)
- Operating pressure: 0.2-1.0 MPa (29-145 PSI)
- Piston speed: 50-800 mm/s (lubricated operation)
- Locking force: 3,850N @ 0.5MPa
- Cushion type: Adjustable rubber buffer + shock absorber
- Port size: G3/8 (BSPP thread)
- Ambient temperature: -10℃ to 80℃ (anti-freeze kit optional)
- Material:
- Barrel: Aluminum alloy AL6061-T6 (hard anodized)
- Piston rod: Chrome-plated S45C steel
- Seals: NBR + PU combination
- Weight: 6.8kg ±3% (without accessories)
- Dimensions:
- Extended length: 465mm
- Retracted length: 315mm
- Body diameter: Ø118mm
- Mounting base: 160×160mm square flange
Heavy-duty clamping cylinder featuring dual safety mechanisms - pneumatic holding force combined with mechanical self-locking. The triple-seal design ensures leak-free operation in high-cycle applications (up to 1.5 million cycles). Integrated guide rods prevent rotational misalignment during clamping operations. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Fixture locking in CNC machining centers
- Press tool securing in stamping machines
- Workpiece positioning in automotive welding lines
- Mold clamping in injection molding setups
- Heavy component retention in material handling systems
Installation guidelines:
Mount vertically with ±3° tolerance. Apply M12×1.75 mounting bolts (Grade 8.8 or higher)
with 45-50N·m torque. Perform weekly lubrication via built-in grease nipples using
ISO VG32 hydraulic oil. Maintain 0.3mm minimum clearance between clamp jaws and workpiece.
| Property | Property Value |
|---|---|
| sku | BSCD100X150S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
| Static Holding Force | 5500N |
