Airtac BSCD Clamp Cylinder BSCD100X160S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X160S Clamp Cylinder Specifications
- Model: BSCD100X160S
- Type: Double-acting compact clamp cylinder
- Bore size: Ø100 mm
- Stroke: 160 mm
- Operating pressure: 0.05–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Cushion type: Adjustable air cushion
- Mounting style: Basic type (MF1) with front flange
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: 5.2 kg ±3%
- Dimensions (L×W×H): 320mm × 120mm × 120mm (extended length)
- Port size: Rc1/4 (G1/4 optional)
- Max thrust: 628N @0.5MPa
- Lubrication: Pre-lubricated (relubrication interval: 3,000km)
High-rigidity clamp cylinder featuring integrated mounting structure and anti-rotation mechanism. The dual piston design ensures stable clamping force distribution, with precision-machined guide rods for minimal deflection. Includes wear-resistant scraper seals and built-in magnetic sensor slots (M9 connector compatible). Requires filtered air with 5-40μm filtration.
- CNC machine tool fixture systems
- Automotive welding jig positioning
- Die casting mold clamping mechanisms
- Robotic material handling end effectors
- Semiconductor wafer processing equipment
Installation note:
Maintain parallel alignment within 0.2mm/m during mounting. Use locknuts with 25-30N·m torque on guide rods.
For vertical installations, add mechanical safety stops. Lubricate guide shafts monthly with ISO VG32 hydraulic oil.
Critical parameters:
Max side load capacity 350N, angular misalignment tolerance ±3°.
Do not exceed 80% of max thrust for continuous operation.
Allow 15mm clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | BSCD100X160S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 160mm |
| Static Holding Force | 5500N |
