Airtac BSCD Clamp Cylinder BSCD100X175
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X175 Clamp Cylinder Specifications
- Model: BSCD100X175
- Type: Double-acting compact clamp cylinder
- Bore size: Ø100mm
- Stroke: 175mm
- Operating pressure: 0.05–0.8 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Standard foot mounting (ISO 15552 compatible)
- Port size: PT1/2 (G1/2 optional)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 5.8kg (without accessories)
- Dimensions: 348mm(L) × 125mm(W) × 125mm(H)
- Rod thread: M20×1.5 (standard)
- Protection rating: IP65 (dust-tight & water jet resistant)
High-force clamping cylinder with space-saving design featuring twin-piston construction for enhanced gripping power. The through-rod design allows symmetrical force distribution, ideal for precision fixturing applications. Includes wear-resistant scraper seals and auto-lubrication bushings for maintenance-free operation.
- Automated welding fixture systems
- CNC machine tool workpiece clamping
- Die casting mold locking mechanisms
- Automotive assembly line positioning jigs
- Robotic material handling end effectors
Installation note:
Maintain 0.5mm minimum clearance between clamp arms and cylinder body during mounting.
Use locknuts with 45-50Nm torque for rod-end connections. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | BSCD100X175 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 175mm |
| Static Holding Force | 5500N |
