Airtac BSCD Clamp Cylinder BSCD100X175S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD Clamp Cylinder BSCD100X175S Technical Specifications
- Model: BSCD100X175S
- Type: Double-acting compact clamp cylinder
- Bore size: 100mm
- Stroke: 175mm
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Standard square body with 4 mounting holes
- Port size: G3/8 (NPT1/4 optional)
- Piston rod thread: M16x1.5
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 3.8kg ±2%
- Dimensions: 250mm(L) x 108mm(W) x 108mm(H)
- Protection rating: IP54 (standard wiper design)
- Lubrication: Pre-lubricated (Use ISO VG32 oil if maintenance required)
High-precision industrial clamp cylinder featuring anti-rotation mechanism and integrated mounting slots. The dual piston design provides 360° clamping force distribution, with hardened guide rods ensuring parallel movement accuracy within ±0.1mm. Special wear-resistant bushing extends service life to over 2,000km travel distance.
- CNC machine tool workpiece fixation
- Automated welding fixture positioning
- Robotic arm end-effector clamping
- Precision mold holding in injection molding
- Electronic component press-fitting systems
Installation note:
Maintain 0.02mm/m alignment tolerance during mounting. Use torque wrench for M8 mounting bolts (recommended 22-25N·m).
For vertical installations, install air vents upward. Lubricate guide rods monthly in high-cycle applications.
Critical parameters:
Maximum side load capacity 150N, axial rotation torque limit 18N·m.
Not suitable for vacuum environments without modification.
| Property | Property Value |
|---|---|
| sku | BSCD100X175S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 175mm |
| Static Holding Force | 5500N |
