Airtac BSCD Clamp Cylinder BSCD100X200S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X200S Clamp Cylinder Technical Specifications
- Model: BSCD100X200S
- Type: Double-acting compact clamp cylinder
- Bore size: 100mm
- Stroke: 200mm
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable pneumatic cushion
- Mounting style: Standard flange (ISO 15552 compatible)
- Port size: 1/4" NPT (G1/8 optional)
- Piston rod thread: M20×1.5
- Material: Aluminum alloy barrel, CR-Steel piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 3.8 kg (without accessories)
- Dimensions: 290mm(L) × 130mm(W) × 130mm(H)
- Repeat positioning accuracy: ±0.5mm
- Max thrust: 706N @0.6MPa
High-rigidity clamping cylinder with integrated mounting structure, featuring anti-rotation mechanism for stable gripping operations. The enhanced guide design minimizes lateral deflection during heavy load applications. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Fixture positioning in CNC machining centers
- Workpiece clamping in automotive assembly lines
- Mold locking mechanisms in plastic injection molding
- Pallet securing systems in logistics automation
- Precision alignment in semiconductor handling
Installation guidelines:
Ensure cylinder axis alignment within ±0.5° tolerance. Apply thread-locking compound
to mounting bolts (recommended torque: 45-50N·m). Maintain 0.3-1.0 MPa lubrication
pressure for air line lubricators.
| Property | Property Value |
|---|---|
| sku | BSCD100X200S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <200mm> |
| Static Holding Force | 5500N |
