Airtac BSCD Clamp Cylinder BSCD100X25
$431.74
Regular price
$439.24
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
BSCD100X25
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、BSCD series is a derivative product line combining standard cylinder with integrated clamping device;
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
Installation guidelines:
Maintain 0.5-1mm clearance between clamp surface and workpiece.
Use torque wrench for mounting bolts (35-40N·m). Lubricate through
air inlet port during initial setup. Avoid side-load exceeding 50N.
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X25 Clamp Cylinder Technical Details
- Model: BSCD100X25
- Type: Compact double-acting clamp cylinder
- Bore size: Ø100mm
- Stroke: 25mm (standard), customizable up to 300mm
- Operating pressure: 0.05–0.8 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Mounting types: Basic type (MF1), foot-mounted (MP2), front flange (MF3)
- Port size: Rc1/4 (standard), G1/4 or NPT1/4 optional
- Piston rod thread: M20×1.5 (standard)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (standard), optional FKM for high temp
- Protection rating: IP54 (standard), IP67 with optional wiper
- Weight: 2.5kg ±3% (without accessories)
- Dimensions: 200mm(L) × 108mm(W) × 108mm(H)
High-rigidity clamp cylinder featuring anti-rotation mechanism and precision ground rod. The hexagonal barrel design enables direct tool engagement for secure clamping operations. Requires ISO VG32 or equivalent hydraulic oil lubrication for optimal performance.
Industrial Applications:
- CNC machine tool workpiece fixation
- Automated welding fixture positioning
- Injection molding machine mold locking
- Robotic arm end-effector clamping
- Semiconductor wafer handling systems
Installation guidelines:
Maintain 0.5-1mm clearance between clamp surface and workpiece.
Use torque wrench for mounting bolts (35-40N·m). Lubricate through
air inlet port during initial setup. Avoid side-load exceeding 50N.
| Property | Property Value |
|---|---|
| sku | BSCD100X25 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <25 mm> |
| Static Holding Force | 5500N |
