Airtac BSCD Clamp Cylinder BSCD100X250S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X250S Clamping Cylinder Technical Details
- Model: BSCD100X250S
- Type: Double-acting clamping cylinder with magnetic piston
- Bore size: Ø100mm
- Stroke: 250mm
- Operating pressure: 0.05–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard MF1 flange (ISO 15552 compatible)
- Port size: G3/8 (NPT1/2 optional)
- Piston rod material: Hard chrome-plated steel
- Seal material: NBR (Nitrile) standard, FKM available on request
- Ambient temperature: -20℃ to +80℃
- Weight: 5.8kg (without accessories)
- Dimensions: 400mm(L) × 125mm(W) × 125mm(H)
- Rod thread: M20×1.5
- Repeat positioning accuracy: ±0.2mm
- Max lateral load capacity: 850N
Heavy-duty clamping cylinder featuring enhanced side load resistance through integrated guide rails and dual piston seals. The S-suffix model includes built-in magnet for position sensing (inductive sensor not included). Optimized for high clamping force applications with 3,140N thrust at 0.6MPa. Requires ISO VG32 hydraulic oil mist lubrication for extended seal life.
- Fixture locking in CNC machining centers
- Pallet clamping in automated assembly lines
- Mold securing in injection molding machines
- Workpiece positioning in robotic welding cells
- Press brake tool holding systems
Installation guidelines:
Maintain 0.1-0.3mm clearance between clamp arm and cylinder body during mounting.
Use anti-vibration washers on mounting bolts. Lubricate rod weekly with Class #2 lithium grease.
| Property | Property Value |
|---|---|
| sku | BSCD100X250S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <250MM> → <250mm> |
| Static Holding Force | 5500N |
