Airtac BSCD Clamp Cylinder BSCD100X300S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X300S Clamp Cylinder Specifications
- Model: BSCD100X300S
- Type: Double-acting clamp cylinder with magnetic piston
- Bore size: 100mm
- Stroke: 300mm
- Operating pressure: 0.15–0.9 MPa
- Cushioning: Adjustable air cushion (both ends)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Port size: G1/2 (ISO standard)
- Mounting type: Basic foot mounting (MF1) with optional accessories
- Repeat positioning accuracy: ±0.5mm
- Weight: 6.8kg (dry, without accessories)
- Dimensions: 480mm(L) × 120mm(W) × 120mm(H) (full extension)
- Rod thread: M20×1.5 (front end)
- Protection rating: IP65 (wipers included)
- Lubrication: Pre-lubricated (Oil-free operation possible)
A heavy-duty clamp cylinder engineered for precision holding applications, featuring enhanced lateral load capacity through integrated guide rods. The hardened piston rod and dual cushioning system ensure smooth operation even at maximum stroke. Built-in magnet in piston enables position sensing with compatible sensors (SM/SD series).
- Fixture locking in CNC machining centers
- Press brake tooling positioning systems
- Automated welding jig clamping
- Die casting machine mold securing
- Pallet locking in FMS (Flexible Manufacturing Systems)
Installation tip:
Maintain 0.5-1mm clearance between clamp arm and workpiece surface during initial setup.
Use locknuts (DIN985) with 35-45 N·m torque for rod-end connections. For vertical mounting,
install air exhaust filters to prevent particle ingress.
| Property | Property Value |
|---|---|
| sku | BSCD100X300S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 300mm |
| Static Holding Force | 5500N |
