Airtac BSCD Clamp Cylinder BSCD100X350S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X350S Clamp Cylinder Technical Details
- Model: BSCD100X350S
- Type: Compact clamp cylinder (double-acting)
- Bore size: Ø100mm
- Stroke: 350mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Basic (no flange) with 4x M6 tapped holes
- Port size: G3/8 (NPT1/4 optional)
- Rod material: Chrome-plated carbon steel (S45C)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR + PU combination
- Temperature range: -10℃ to 80℃
- Weight: 6.8kg (dry, without accessories)
- Dimensions: 500mm(L) × 125mm(W) × 125mm(H)
- Max thrust: 785N @ 0.7MPa
- Piston speed: 50–800mm/s
- Protection rating: IP54 (standard seals)
High-rigidity clamping cylinder optimized for precision gripping applications. Features dual anti-rotation pins (Ø12mm) and reinforced end caps to withstand lateral forces during clamping operations. The low-profile design allows installation in confined spaces while maintaining 20% higher holding force compared to standard series.
- Fixture positioning in CNC machining centers
- Workpiece retention in automotive welding lines
- Mold clamping in injection molding machines
- Pallet locking in automated storage systems
- Press tool alignment devices
Installation protocol:
Requires parallel alignment within ±0.5° deviation. Use M6×20 grade 8.8 bolts
(24Nm torque) with spring washers. Lubricate rod with ISO VG32 hydraulic oil
during initial commissioning. Avoid side load exceeding 150N.
| Property | Property Value |
|---|---|
| sku | BSCD100X350S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 350mm |
| Static Holding Force | 5500N |
