Airtac BSCD Clamp Cylinder BSCD100X400S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X400S Clamp Cylinder Technical Details
- Model Code: BSCD100X400S
- Type: Double-acting clamp cylinder with mechanical lock
- Bore size: Ø100 mm
- Stroke: 400 mm
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Cushioning: Adjustable hydraulic buffer + rubber pad
- Port size: PT1/2 (G1/2 optional)
- Mounting: Standard MF1 flange with 4×M12 mounting holes
- Rod end: M20×1.5 external thread
- Seal material: NBR + special wear-resistant ring
- Temperature range: -10℃ to 80℃ (extended range -20℃ to 120℃ with optional seals)
- Weight: 12.5 kg ±3%
- Dimensions: 600mm(L) × 138mm(W) × 138mm(H) (full extension)
- Rod torque resistance: ≤0.5° at max load
- Repeat positioning accuracy: ±0.2 mm
Heavy-duty clamp cylinder featuring dual-stage locking mechanism with 360° radial holding force. The hardened chromium piston rod (HRC 45-50) and double-lip seals ensure leak-free operation in high-vibration environments. Integrated guide grooves allow direct sensor mounting for position feedback.
- Fixture clamping in CNC machining centers
- Mold locking systems for injection molding machines
- Workpiece positioning in automotive welding lines
- Heavy component retention in die casting operations
- Press brake tool securing systems
Installation protocol:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended) every 500,000 cycles.
Maintain 0.3-0.6 MPa holding pressure during clamping phase. Avoid side-load exceeding 150N.
| Property | Property Value |
|---|---|
| sku | BSCD100X400S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <400mm> |
| Static Holding Force | 5500N |
