Airtac BSCD Clamp Cylinder BSCD100X450S
2、Enables locked stoppage at any position within the stroke range during operation;
3、Features optimized clamping mechanism that maintains locking state regardless of piston movement direction.
Category: Standard Cylinders , Brand: AirTAC , Series: BSCD
AirTAC BSCD100X450S Clamp Cylinder Specifications
- Model: BSCD100X450S
- Type: Compact series double-acting clamp cylinder
- Bore size: Ø100mm
- Stroke: 450mm
- Operating pressure: 0.05–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard square flange (ISO 15552 compatible)
- Port size: G1/2 (BSPP thread)
- Piston rod thread: M20×1.5
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 5.8kg (excluding accessories)
- Dimensions: 550mm(L) × 125mm(W) × 125mm(H)
High rigidity clamping cylinder with reinforced guide structure, designed for heavy-duty holding applications requiring precise positioning. Features wear-resistant rod bearing and integrated cushion adjustment screws. The S-suffix model includes pre-drilled mounting holes for magnetic switches (sensor ready).
- Fixture clamping in CNC machining centers
- Workpiece positioning in automotive welding lines
- Mold locking in injection molding machines
- Heavy part retention in assembly automation
- Press brake tool holding systems
Installation note:
Ensure proper alignment of clamping surfaces (parallelism ≤0.1mm/m).
Use locknuts with 25-30Nm torque for rod-end fittings.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
Critical parameters:
Maximum side load capacity 350N,
Do not exceed 0.8m/s piston speed without external shock absorbers,
Requires 5μm filtered air with oil mist (ISO 8573-1:2010 Class 4.4.2)
| Property | Property Value |
|---|---|
| sku | BSCD100X450S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 450mm |
| Static Holding Force | 5500N |
