Airtac CM3HS Selector Mechanical Valve CM3HS06-P1
$9.73
Regular price
$17.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3HS06-P1
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. CM3B, CM3L, CM3V, and CM3R series require external mechanisms to provide actuation force for valve switching, suitable for position sensing or limit switch applications;
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
Installation guidelines:
Use M5 mounting screws with 0.6-0.8Nm torque. Lubricate pilot pins with ISO VG32 hydraulic oil during maintenance.
Avoid lateral forces on manual lever during operation.
Critical note:
Requires 5μm filtration (40μm for emergency use). Do NOT use silicone-based lubricants
which may degrade HNBR seals. Maintain 15mm clearance below valve for condensate drainage.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
AirTAC CM3HS06-P1 Selector Mechanical Valve Technical Details
- Model: CM3HS06-P1
- Type: 3-position selector valve (Mechanical spring return)
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow rate: 800 L/min (ANR)
- Actuation force: 15N±3N (manual operation)
- Valve body material: Die-cast aluminum alloy (hard anodized)
- Seal material: HNBR (hydrogenated nitrile) for high temp resistance
- Temperature range: -10℃ to 120℃ (with intermittent peak at 150℃)
- Weight: 480g ±5%
- Dimensions: 76mm(L) × 54mm(W) × 45mm(H)
- Mounting pattern: ISO 5599-1 compliant
- Response time: ≤50ms (full stroke)
- Leakage: ≤20 cm³/min @ 0.5MPa
Heavy-duty mechanical selector valve with positive center position, designed for precise directional control in high-cycle industrial applications. Features wear-resistant seals and anti-vibration lock mechanism. Includes manual override for system debugging and emergency operation.
Industrial Applications:
- Pneumatic press clamping systems
- Automated assembly line tooling switches
- Material handling equipment direction control
- Plastic injection molding machine actuators
- Test bench pneumatic circuit configuration
Installation guidelines:
Use M5 mounting screws with 0.6-0.8Nm torque. Lubricate pilot pins with ISO VG32 hydraulic oil during maintenance.
Avoid lateral forces on manual lever during operation.
Critical note:
Requires 5μm filtration (40μm for emergency use). Do NOT use silicone-based lubricants
which may degrade HNBR seals. Maintain 15mm clearance below valve for condensate drainage.
| Property | Property Value |
|---|---|
| sku | CM3HS06-P1 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
