Airtac CM3HS Selector Mechanical Valve CM3HS08G
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
AirTAC CM3HS08G Selector Mechanical Valve Technical Details
- Model: CM3HS08G (ISO symbol compliant)
- Type: 3-position selector valve with manual override
- Port configuration: 5 ports/3 positions (5/3-way)
- Port size: G1/8 (BSPP thread) with 8mm push-in fittings
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Max flow rate: 750 L/min (ANR) at 0.5 MPa
- Actuation type: Mechanical lever with detent positions
- Body material: Anodized aluminum alloy (ADC12)
- Seal material: Heat-resistant NBR (-10℃ to 80℃)
- Weight: 320g ±5% (including fittings)
- Dimensions: 58mm(W) × 48mm(H) × 95mm(L)
- Mounting: Panel mount with M4 screw holes
- Vibration resistance: 10–55Hz @ 1.5mm amplitude
- Leakage: <10 bubbles/min under ISO 6953-2 test
Industrial-grade manual selector valve featuring center closed/center exhaust configurations. The dual-pilot operated design enables precise mid-position control with tactile position feedback. Enhanced wear resistance through hardened steel pivot points and PTFE-coated spool. Compatible with ISO 8573-1 Class 3 compressed air.
- Machine tool clamping/unclamping sequences
- Production line emergency stop circuits
- Material handling system diverters
- Plastic injection molding mode selection
- Test bench pneumatic circuit isolation
Operation guidance:
Apply 20–30N force when switching positions. Lubricate pivot points
every 50,000 cycles using ISO VG32 turbine oil. Avoid side-loading
the actuator lever during operation.
Contains brass components -
Not suitable for oxygen-enriched atmospheres or ammonia-based gases.
