Airtac CM3L One-way Roller Lever Type Mechanical Valve CM3L08G
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations, optimized for varied operational conditions;
3. Poppet valve design ensures excellent sealing performance, positive directional control, and maintenance-free operation without lubrication;
4. Multi-position mounting capability simplifies installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series employ metallic actuators for extended service life and consistent reliability in demanding environments;
6. CM3PMS and CM3PMX models incorporate metal protective guards to shield pushbuttons from accidental actuation and mechanical interference, ensuring secure operation.
Category: Mechanical Valves , Brand: AirTAC , Series: CM3L Unidirectional Roller Lever Mechanical Valve
AirTAC CM3L08G Unidirectional Roller Lever Mechanical Valve Specifications
- Model: CM3L08G (Lever-Operated Series)
- Type: 3/2-way normally closed (mechanical actuation)
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.1–0.7 MPa
- Operating force: ≤3N (lever actuation)
- Lever stroke: 2.5±0.3mm
- Valve body material: Anodized aluminum alloy
- Seal material: HNBR (hydrogenated nitrile) for enhanced oil resistance
- Temperature range: -20℃ to 80℃ (non-freezing conditions)
- Flow capacity: 350 NL/min (at 0.5 MPa)
- Weight: 215g ±5% (including mounting hardware)
- Dimensions: 54mm(L) × 38mm(W) × 72mm(H) (excluding lever protrusion)
- Actuation cycles: ≥1,000,000 operations (JIS B8377 standard)
- Mounting: Direct panel mounting with M4 screws (included)
Mechanically actuated valve with roller-lever mechanism for precise tactile control, featuring anti-vibration lock structure and wear-resistant pivot design. The chrome-plated steel roller minimizes friction during actuation, while the dual-spring return system ensures positive shutoff. Compatible with ISO 8573-1 Class 3 compressed air.
- Safety door interlocks in automated assembly lines
- Position confirmation in material handling systems
- Jig clamping sequence control
- Emergency stop override systems
- Packaging machine product detection gates
Installation note:
Align lever travel path with mechanical actuator (recommended 80-90° actuation angle).
Apply thread sealant to port connections and torque to 1.2-1.5N·m.
Lubricate pivot point with ISO VG32 turbine oil quarterly.
| Property | Property Value |
|---|---|
| sku | CM3L08G |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
