Airtac CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS05B
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override with multi-configuration actuators for diverse operational conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-directional mounting options enhance installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series adopt metallic actuators for extended service life and superior reliability;
6. CM3PMS and CM3PMX series incorporate an integrated protective metal shroud to shield the button cap, preventing accidental actuation and ensuring operational safety.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PMS
AirTAC CM3PMS05B Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PMS05B
- Type: 3/2-way manual reset mechanical valve (push-to-actuate)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.05–0.8 MPa
- Max flow rate: 450 NL/min (at 0.5 MPa)
- Actuation force: 3–5 N
- Body material: Anodized aluminum alloy (black finish)
- Seal material: Heat-resistant NBR (nitrile rubber)
- Button diameter: 40mm (mushroom head)
- Temperature range: -10℃ to 80℃ (with intermittent peaks to 100℃)
- Weight: 220g ±5%
- Dimensions: 56mm(L) × 56mm(W) × 78mm(H) (excluding mounting bracket)
- Mounting style: Panel mount (16mm cutout required)
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
Emergency-stop style manual valve with large tactile mushroom head for quick operation. Features positive-lock mechanism with twist-to-release safety function. The zinc-plated steel spring ensures consistent reset force across temperature variations. Integrated O-ring groove allows direct panel mounting without additional seals.
- Emergency stop systems in pneumatic conveyors
- Manual override in automated assembly lines
- Safety interlocks for press machinery
- Process interruption in chemical dosing systems
- Mobile equipment manual control stations
Installation note:
Requires 20mm clearance behind panel for full button travel.
Apply silicone grease (ASG-65 recommended) to stem annually.
Test reset function monthly under pressure.
| Property | Property Value |
|---|---|
| sku | CM3PMS05B |
| Position | 3-Port 2-Position |
| Port Size | M5 |
