Airtac CM3PMX Large Mushroom Head Button Type Mechanical Valve CM3PMX06B
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations, enabling flexible deployment under various working conditions.
3. Poppet valve design ensures superior sealing performance, smooth directional switching, and maintenance-free operation without lubrication requirements.
4. Supports multiple mounting orientations for simplified installation and space optimization.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and reliable long-term performance.
6. CM3PMS and CM3PMX series are equipped with metal protective covers to shield the pushbutton cap from accidental impacts and prevent unintended actuation, ensuring operational safety and reliability.
Category: Mechanical Valves, Brand: AIRTAC, Series: CM3PMX
AirTAC CM3PMX06B Large Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PMX06B
- Type: Push-button mechanical valve (manual reset)
- Operation style: Mushroom head emergency stop design
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.1–0.8 MPa
- Actuation force: 50N ±10%
- Body material: Stainless steel (SUS303) with zinc alloy handle
- Seal material: High-grade NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Contact rating: 5A 250VAC (gold-plated contacts)
- Mechanical life: ≥500,000 cycles
- Protection rating: IP67 (dust/water resistant)
- Weight: 210g ±5g
- Dimensions: 50mm(D) × 50mm(W) × 65mm(H)
- Mounting: M20×1.5 threaded base
- Certification: CE, RoHS compliant
Industrial-grade emergency stop valve featuring a distinctive oversized red mushroom head for instant machine shutdown. The chrome-plated stainless steel construction ensures corrosion resistance in harsh environments, while the dual-contact design prevents accidental resetting. Requires manual pull-to-reset operation after activation.
- Production line emergency stop systems
- Packaging machinery safety interlocks
- Elevator control panels
- Press machine safety circuits
- Robotic cell perimeter safety
Installation guidelines:
Mount within operator's immediate reach (max 600mm height from floor level).
Perform monthly contact resistance checks (≤100mΩ) and annual seal replacement.
Avoid installation in areas with oil mist concentration >5mg/m³.
| Property | Property Value |
|---|---|
| sku | CM3PMX06B |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
