Airtac CM3PMX Large Mushroom Head Button Type Mechanical Valve CM3PMX06Y
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations, enabling flexible deployment under various working conditions.
3. Poppet valve design ensures superior sealing performance, smooth directional switching, and maintenance-free operation without lubrication requirements.
4. Supports multiple mounting orientations for simplified installation and space optimization.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and reliable long-term performance.
6. CM3PMS and CM3PMX series are equipped with metal protective covers to shield the pushbutton cap from accidental impacts and prevent unintended actuation, ensuring operational safety and reliability.
Category: Mechanical Valves, Brand: AIRTAC, Series: CM3PMX
AirTAC CM3PMX06Y Large Mushroom Head Push Button Mechanical Valve
- Model: CM3PMX06Y
- Type: 3/2-way manual reset mechanical valve (normally closed)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.2–0.8 MPa
- Operating force: ≤5N (emergency stop activation)
- Actuation type: Mushroom head (Ø30mm yellow cap)
- Body material: Brass with nickel plating
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Mechanical life: ≥1,000,000 cycles
- Protection rating: IP65 (dust-tight & water jet resistant)
- Weight: 215g ±5g
- Dimensions: 50mm(L) × 50mm(W) × 60mm(H)
- Mounting: Panel mounting (requires 22mm cutout)
- Contact type: SPDT electrical contacts (1NO+1NC)
- Contact rating: 5A 250VAC (resistive load)
Safety-rated emergency stop valve with oversized tactile mushroom head for immediate system shutdown. Features positive-lock mechanism requiring manual twist-release for resetting. The dual-contact design allows simultaneous pneumatic circuit cutoff and electrical signal transmission. Corrosion-resistant construction with ergonomic 30mm diameter actuator surface.
- Press machine emergency stop systems
- Assembly line safety interlocks
- Packaging equipment emergency cutoff
- Robotic workcell perimeter safety stations
- Injection molding machine safety protocols
Installation requirements:
Must be installed within 0.6m operator reach height (500-1600mm from floor).
Requires monthly functional test per ISO 13850 standards.
Use M3.5 screws for panel mounting (max torque 0.8N·m).
| Property | Property Value |
|---|---|
| sku | CM3PMX06Y |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
