Airtac CM3PMX Large Mushroom Head Button Type Mechanical Valve CM3PMX08B
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations, enabling flexible deployment under various working conditions.
3. Poppet valve design ensures superior sealing performance, smooth directional switching, and maintenance-free operation without lubrication requirements.
4. Supports multiple mounting orientations for simplified installation and space optimization.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and reliable long-term performance.
6. CM3PMS and CM3PMX series are equipped with metal protective covers to shield the pushbutton cap from accidental impacts and prevent unintended actuation, ensuring operational safety and reliability.
Category: Mechanical Valves, Brand: AIRTAC, Series: CM3PMX
AirTAC CM3PMX Series Large Mushroom Head Push Button Mechanical Valve CM3PMX08B
- Model: CM3PMX08B
- Type: Push-button mechanical valve (3/2-way)
- Operation: Spring return with emergency stop function
- Port size: PT1/8 (G1/8 equivalent)
- Operating pressure: 0.05–0.8 MPa
- Max flow rate: 850 L/min (ANR)
- Actuation force: 25-35N (ergonomic design)
- Contact rating: 5A 250VAC (gold-plated contacts)
- Mechanical life: ≥500,000 cycles
- Temperature range: -5℃ to 60℃
- Body material: Reinforced PBT with UV protection
- Seal material: Oil-resistant NBR
- Protection rating: IP67 (dust/water resistant)
- Weight: 320g ±5g
- Dimensions: 68mm(D) × 68mm(H) × 45mm(W)
Industrial-grade emergency stop valve featuring a 38mm oversized mushroom head for quick palm activation. The dual-color (red/yellow) indicator ring provides immediate visual status feedback. Designed with anti-vibration locknuts and a stainless steel spring mechanism for harsh environments.
- Production line emergency stop systems
- Press machine safety interlocks
- Robotic cell access control
- Packaging equipment jam release
- CNC machine tool safety circuits
Installation guidelines:
Mount within 45° of vertical plane. Requires 50mm clearance below
for full button depression. Use M4 screws with 0.7Nm torque limit.
Test weekly using the built-in manual override slot.
| Property | Property Value |
|---|---|
| sku | CM3PMX08B |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
