Airtac CM3PMX Large Mushroom Head Button Type Mechanical Valve CM3PMX08Y
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations, enabling flexible deployment under various working conditions.
3. Poppet valve design ensures superior sealing performance, smooth directional switching, and maintenance-free operation without lubrication requirements.
4. Supports multiple mounting orientations for simplified installation and space optimization.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and reliable long-term performance.
6. CM3PMS and CM3PMX series are equipped with metal protective covers to shield the pushbutton cap from accidental impacts and prevent unintended actuation, ensuring operational safety and reliability.
Category: Mechanical Valves, Brand: AIRTAC, Series: CM3PMX
AirTAC CM3PMX Mushroom Head Push Button Mechanical Valve CM3PMX08Y Specifications
- Model: CM3PMX08Y
- Type: Normally closed mechanical valve (manual reset)
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.2–0.8 MPa
- Operating force: 50N ±10%
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Button diameter: 40mm (oversized mushroom head)
- Temperature range: -20℃ to 80℃
- Protection rating: IP67 (dust/water resistant)
- Mounting style: Panel mount with M18×1.5 thread
- Weight: 220g ±5%
- Dimensions: 48mm(D) × 48mm(D) × 65mm(H)
- Contact rating: 5A 250VAC (gold-plated contacts)
- Mechanical life: ≥500,000 cycles
Emergency stop valve featuring a highly visible red mushroom head with latch-type mechanical actuation. Engineered for instant system shutdown in critical situations, with positive mechanical engagement that prevents accidental reset. The zinc-plated stainless steel spring ensures reliable operation even in high-vibration environments.
- Emergency stop systems for CNC machinery
- Safety interlocks on automated production lines
- Conveyor belt emergency cutoff switches
- Robotic cell safety perimeter controls
- Press machine two-hand control systems
Installation guidelines:
Mount within 45° of vertical position using included locknut.
Maintain minimum 25mm clearance around button perimeter for full actuation.
Test monthly by performing full depression and twist-to-reset operation.
| Property | Property Value |
|---|---|
| sku | CM3PMX08Y |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
