Airtac F-JCK-AM Clamping Arm F-JCK40AM1C
AirTAC F-JCK-AM Clamping Arm F-JCK40AM1C Technical Specifications
- Model: F-JCK40AM1C
- Type: Compact linear clamping arm with mechanical lock
- Clamping force: 1,500N (at 0.5MPa)
- Stroke length: 40mm (adjustable via stopper)
- Operating pressure: 0.2–0.7 MPa
- Piston diameter: Φ32mm
- Rod thread: M10×1.5
- Weight: 0.82kg ±2%
- Dimensions: 150mm(L) × 40mm(W) × 50mm(H)
- Body material: Aluminum alloy (A6063-T5)
- Surface treatment: Hard anodized (25μm thickness)
- Operating temperature: -10℃ to 80℃
- Repeat positioning accuracy: ±0.02mm
- Mounting pattern: 2×M5 threaded holes (depth 8mm)
Precision-engineered clamping arm featuring dual guide rods and anti-vibration design for stable workpiece fixation. Integrated shock absorbers reduce impact noise by 30% compared to standard models. Includes wear-compensation mechanism for prolonged service life (500,000+ cycles). Compatible with ISO 6432 pneumatic standards.
- CNC machine tooling jigs
- Automotive part welding fixtures
- PCB assembly line positioning
- Optical lens polishing stations
- Battery module pressing systems
Installation protocol:
Apply Loctite 243 to mounting screws (torque ≤4.5N·m).
Perform air bleeding after initial installation. Lubricate guide rods monthly with ISO VG32 hydraulic oil.
Caution:
Do not exceed 0.8MPa pressure. Avoid side-load forces >200N.
For vertical mounting, install secondary safety catch (sold separately).
| Property | Property Value |
|---|---|
| sku | F-JCK40AM1C |
| Clamping Arm Model Code | Offset 15mm |
| Bore Diameter | <40mm> |
