Airtac F-JCK-AM Clamping Arm F-JCK40AM1R
AirTAC F-JCK-AM Clamping Arm F-JCK40AM1R Technical Specifications
- Model: F-JCK40AM1R (Standard Rotation Type)
- Series: F-JCK-AM Modular Clamping Unit
- Clamping force: 160-230N (adjustable via air pressure)
- Stroke per jaw: 8mm (mechanical stroke)
- Operation: Double-acting pneumatic control
- Operating pressure: 0.2-0.7 MPa
- Ambient temperature: -10℃ to 60℃
- Material:
- Main body: Aluminum alloy (A6063-T5)
- Claw: SCM440 hardened steel (HRC48-52)
- Surface treatment: Black anodized (body), phosphate coating (moving parts)
- Weight: 1.25kg ±2% (including all mounting hardware)
- Dimensions:
- Height: 56mm (base to top of pivot)
- Width: 42mm (arm span at neutral position)
- Depth: 78mm (front mounting surface to rear connector)
- Rod end thread: M6×1.0 internal (for custom tooling attachment)
- Repeat accuracy: ±0.02mm
- Air consumption: 4.5L/min (at 0.5MPa)
- Lubrication: Pre-lubricated (maintenance-free for 5,000km operation)
Modular clamping unit with self-locking cam mechanism, designed for precision workpiece positioning in automated systems. Features zero-backlash roller bearings and dual guided shafts for parallel jaw movement. Integrated air ports allow daisy-chaining of multiple units (requires AIR-VCM4 manifold for synchronized control).
- CNC machine tooling: Fixture locking during milling/drilling
- Electronics assembly: PCB panel retention for soldering robots
- Automotive lines: Engine component positioning in leak test stations
- Packaging systems: Product stabilization during labeling/coding
- Medical device manufacturing: Secure delicate parts during laser marking
Installation protocol:
Mount on ISO-standard 40mm spaced holes (2×M5 threaded). For optimal performance:
- Use C-R-LUBE2 grease on guide rails every 8M cycles
- Maintain 0.3-0.5MPa filtered air supply (5μm filter required)
- Install shock absorbers if cycle rate exceeds 120CPM
| Property | Property Value |
|---|---|
| sku | F-JCK40AM1R |
| Clamping Arm Model Code | Offset 15mm |
| Bore Diameter | <40mm> |
