Airtac F-JCK-AM Clamping Arm F-JCK63AM3R
AirTAC F-JCK-AM Clamping Arm F-JCK63AM3R Technical Details
- Model: F-JCK63AM3R (Standard Type)
- Clamping force: 2,550 N (at 0.5 MPa)
- Stroke length: 30±1 mm
- Operating pressure: 0.15–0.7 MPa
- Piston diameter: Ø63 mm
- Rod thread: M12×1.75
- Weight: 3.8 kg ±5%
- Dimensions: 220mm(L) × 95mm(W) × 95mm(H)
- Body material: Anodized aluminum alloy (A6063-T5)
- Seal type: NBR+PU hybrid seals
- Temperature range: -10℃ to 80℃
- Repeat accuracy: ±0.05 mm
- Mounting pattern: 4×M6 threaded holes (14mm spacing)
High-precision industrial clamping unit with self-locking wedge mechanism, featuring dual guide rods for enhanced stability during heavy-duty operations. The nickel-plated piston rod provides corrosion resistance in humid environments. Requires regular lubrication (ISO VG32 hydraulic oil recommended).
- CNC machine tool workpiece positioning
- Automotive welding fixture systems
- PCB drilling equipment clamping
- Die-casting mold securing
- Robotic material handling end effectors
Installation guidelines:
Align within 0.2mm perpendicularity tolerance during mounting.
Use torque-controlled tightening (8-10 N·m for M6 bolts).
Perform 50 empty cycles before load operation.
| Property | Property Value |
|---|---|
| sku | F-JCK63AM3R |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | 63mm |
