Airtac F-JCK-LM Adjustment Screw F-JCK50X120LM
AirTAC F-JCK-LM Adjusting Screw F-JCK50X120LM Technical Specifications
- Full Model: F-JCK50X120LM
- Series: Fine Adjustment Screw (LM Series)
- Material: S45C Carbon Steel (JIS G4051)
- Thread Diameter: M8×1.25 (Metric Fine Thread)
- Effective Length: 120±0.5mm
- Total Length: 135mm (including mounting features)
- Hexagon Size: 12mm AF
- Weight: 480±10g
- Dimensions: Ø50mm (Flange) × 120mm (Threaded Shaft Length)
- Surface Treatment: Black Oxide Coating (Fe3O4)
- Hardness: HRC 28-32 (Core) / HRC 45-50 (Surface Case Hardened)
- Torque Range: 5-20 N·m (Recommended Operational)
- Temperature Resistance: -30℃ to +120℃
- Corrosion Resistance: 96hrs Neutral Salt Spray Test
- Axial Load Capacity: 2,500N Static / 1,800N Dynamic
- Parallelism: ≤0.02mm (Flange Mounting Surface)
- IP Rating: IP54 (Dust Protected & Splash Resistant)
Precision-engineered adjustment screw with hardened contact surfaces and anti-backlash design. Features dual-stage sealing (O-ring + thread locker compound) for vibration resistance in high-cycle applications. The graduated scale (0.5mm increments) enables micron-level positional adjustments through vernier principle alignment.
- Pneumatic cylinder stroke fine-tuning in assembly robots
- Position calibration of optical sensors in semiconductor handlers
- Mechanical stop adjustment for CNC tooling fixtures
- Z-axis compensation in PCB drilling machines
- Clamping force regulation in injection molding ejectors
Installation Protocol:
Apply medium-strength thread locker (Loctite 243 equivalent) on clean threads.
Use calibrated torque wrench with 12mm crowfoot adapter.
Re-torque after 50 operating cycles. Lubricate quarterly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | F-JCK50X120LM |
| Bore Diameter | <50mm> |
| Adjustment Angle | 120° |
