Airtac F-JCK-LM Adjustment Screw F-JCK50X135LM
AirTAC F-JCK-LM Adjusting Screw F-JCK50X135LM Technical Details
- Full model: F-JCK50X135LM
- Series: F-JCK-LM precision adjustment series
- Material: Carbon steel (SCM435 equivalent)
- Surface treatment: Black oxide coating
- Total length: 135±0.5mm
- Thread specification: M6×1 pitch
- Effective thread length: 50mm
- Hexagon socket size: 3mm (Allen key)
- Weight: 228±5g
- Dimensions: 135mm(L) × 14mm(Diameter) × 14mm(Hex flats)
- Hardness: HRC 28-32 core / HRC 45-50 surface
- Torque range: 1.5-2.5N·m (recommended installation torque)
- Temperature range: -20℃ to 120℃
- Corrosion resistance: 96hrs salt spray test compliant
- Compatible cylinders: MAL/MALH/MAJ series 50mm bore
Precision-machined stroke adjustment screw with anti-loosening structure, featuring dual-stage surface hardening for wear resistance. The knurled grip section enables tool-free coarse adjustment, while the hex socket allows fine-tuning. Integrated O-ring groove design maintains alignment stability in high-vibration environments.
- Pneumatic cylinder end-position cushioning adjustment
- Automated assembly line positioning mechanisms
- Packaging machine stroke limitation systems
- Robotic arm joint movement calibration
- CNC tool changer position fine-tuning
Installation protocol:
Apply thread locker (Loctite 243 recommended) to the first 3 threads before installation.
Perform torque verification after 24hrs of initial operation. Maximum angular adjustment
range: ±180° from neutral position. Lubricate monthly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | F-JCK50X135LM |
| Bore Diameter | <50mm> |
| Adjustment Angle | 135° |
