Airtac PHW F Thread Swivel Tee Fitting PHW1204-S
AirTAC PHW F-Type Threaded Swivel Tee Connector PHW1204-S Technical Details
- Model: PHW1204-S
- Series: PHW (Compact Swivel Series)
- Type: 360° Rotatable T-shaped connector
- Thread Standard: BSPP (G-thread) / NPT optional
- Port Configuration: 1/8" (F-F-F triple female threads)
- Material: Lead-free brass (CuZn39Pb3) with nickel plating
- Surface Hardness: ≥HV200
- Pressure Rating: 0.05-1.5 MPa (7-217 PSI)
- Burst Pressure: ≥3.0 MPa
- Temperature Range: -5℃ to 80℃ (23℉ to 176℉)
- Seal Material: NBR (Nitrile) O-rings
- Weight: 28.5g ±0.5g
- Dimensions: 30mm(L) × 30mm(W) × 28mm(H)
- Thread Engagement: 5 full turns minimum
- Torque Resistance: ≤3 N·m tightening torque
- Vibration Test: Passes 10Hz-55Hz, 1.5mm amplitude
Three-way swivel joint featuring tool-free 360° rotation adjustment capability, designed for flexible branch line connections in confined spaces. The nickel-plated brass construction provides corrosion resistance in humid environments. Integrated NBR seals ensure leak-proof performance under cyclic pressure conditions.
- Pneumatic tool air line distribution
- Industrial robot end-effector plumbing
- CNC machine coolant line splitting
- Packaging machine actuator networks
- Laboratory gas chromatography setups
Installation note:
Apply pipe sealant only on male threads (not female ports).
Rotate body clockwise until 2-3 threads remain visible for proper alignment.
Avoid overtightening beyond 3 N·m to prevent brass deformation.
| Property | Property Value |
|---|---|
| sku | PHW1204-S |
