Airtac SAID63 Double Rod Cylinder SAID63X100
The AirTAC Airtac SAID63 Double Rod Cylinder SAID63X100 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID63 Double Rod Cylinder SAID63X100
The AirTAC SAID63X100 is a double-acting, double-rod ISO 15552 profile cylinder featuring a 63mm bore and 100mm stroke. Because a carbon steel rod exits both end covers, the effective piston area is identical in each direction, yielding an equal extend and retract force of 1402 N at 0.5 MPa. This symmetric output is ideal for mechanisms requiring consistent power on both strokes.
The twin-rod architecture allows you to mount the primary workpiece on the front rod while using the rear protrusion for a position flag, cam, or secondary actuation. It utilizes a PT G3/8 port, offers adjustable air cushioning at both ends, and features dual-side sensor grooves for flexible switch mounting. Note that this standard configuration omits the piston magnet; adding the -S option enables compatibility with AirTAC CMSE reed and DMSE electronic sensors.
Airtac SAID63 Double Rod Cylinder SAID63X100 Technical Specifications
| Model | Airtac SAID63 Double Rod Cylinder SAID63X100 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | — |
| Max (@1.0 MPa) | 286 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID63 Double Rod Cylinder SAID63X100
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 63 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID63 Double Rod Cylinder SAID63X100 Is Used
Symmetric Transfer
Drives a transfer carriage with equal 1402 N force extending and retracting, ensuring consistent movement speeds for parts shifting between stations.
Anti-Rotation Slide
The twin carbon steel rods guide the load against twisting, keeping a precision sliding tool perfectly aligned without external guide rails.
Rear-Rod Sensing
Mounts the work tool on the front rod while using the rear rod extension to trigger a limit flag or secondary mechanism in a compact space.
Is the Airtac SAID63 Double Rod Cylinder SAID63X100 the Right Cylinder?
Select this 63mm bore when an application demands matched push and pull forces of 1402 N at 0.5 MPa, stepping up from the 50mm bore (825 N) for higher capacity, or down from the 80mm bore (2268 N) if space is constrained. A double-rod design is preferred over a single-rod SAI when the load requires dual-side guidance to prevent rotation, or when a rear rod is needed to trip a limit switch. As a true ISO 15552 profile cylinder, it serves as a direct replacement for other ISO 15552 double-rod cylinders using the same bore, stroke, PT G3/8 port, and mounting accessories (Basic, FA, LB, TC, FTC, TCM1, TCM2).
Keep in mind the adjustable air cushions only decelerate the piston near stroke ends; they do not lock the load. If the mechanism must hold position without live air pressure, consider an external pilot-operated check valve, a SAIL lock cylinder, or a BSAID clamp-lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID63 Double Rod Cylinder SAID63X100 FAQ
Because it is a double-rod cylinder, the effective area is the same on both sides. It delivers an equal push and pull force of 1402 N at 0.5 MPa, 1962 N at 0.7 MPa, and 2523 N at 0.9 MPa.
Yes. The SAID63X100 is an ISO 15552 profile cylinder, making it dimensionally interchangeable with other ISO 15552 double-rod cylinders of the same bore and stroke, provided you match the PT G3/8 port and mounting interface.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
Request a Quote for Airtac SAID63 Double Rod Cylinder SAID63X100
Send us the quantity and destination. We confirm price, stock and lead time — usually within 7-8 hours.
