Airtac SCLB Rear Lock-Type Cylinder SCLB40X100
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB40X100 Locking Cylinder Specifications
- Model: SCLB40X100
- Type: Double-acting cylinder with mechanical lock
- Bore size: 40mm
- Stroke: 100mm
- Operating pressure: 0.1–0.9 MPa
- Locking method: Manual release lever (standard) / Optional solenoid release
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (MF1) with front/rear threaded mounting
- Port size: G1/8 (M5×0.8 optional)
- Temperature range: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated steel (SUS304 equivalent)
- Seals: NBR (standard) / Optional FKM for high temp
- Weight: 1.45kg (excluding accessories)
- Dimensions:
- Extended length: 240mm (minimum)
- Retracted length: 140mm (minimum)
- Body diameter: 50mm
- Rod end thread: M16×1.5
High-precision locking cylinder featuring dual-position mechanical brake mechanism. The integrated wedge-block locking system provides ISO 15552 compliant holding force (up to 1,200N static load). Includes wear-resistant guide bushings and anti-rotation piston rod. Requires 5-40μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 purity.
- Vertical load holding in automated assembly lines
- Emergency stop positioning in injection molding machines
- Safety locking for robotic arm end effectors
- Position retention in material handling elevators
- Process interruption recovery systems
Installation note:
Locking mechanism requires manual release before initial operation.
Maintain 0.3mm minimum clearance between rod end and load during alignment.
Lubricate with ISO VG32 hydraulic oil (NBR seals) or synthetic grease (FKM seals).
| Property | Property Value |
|---|---|
| sku | SCLB40X100 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
| Lock Position | Rear Cover with Lock Type |
