Airtac SCLB Rear Lock-Type Cylinder SCLB40X125-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB40X125-S Locking Cylinder Specifications
- Model: SCLB40X125-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: 40mm
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.1–1.0 MPa
- Locking force: 1,570N @ 0.5MPa (calculated: F=P×A)
- Locking method: Dual-piston wedge mechanism
- Operation direction: Bidirectional locking (axial direction)
- Cushioning: Adjustable rubber buffer + shock absorber
- Mounting type: Standard foot mounting (ISO 15552)
- Port size: M5x0.8 (G1/8 optional)
- Seal material: NBR (Nitrile) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Weight: 2.8kg (Approx. with lock unit)
- Dimensions: 268mm(L) × 53mm(W) × 53mm(H) (Fully retracted)
- Rod thread: M16×1.5 external thread
- Protection rating: IP54 (standard), IP67 optional
Industrial-grade locking cylinder featuring fail-safe position retention through a precision-engineered wedge locking system. The dual-piston mechanism provides symmetrical clamping force distribution, ensuring zero drift during emergency stops or power failures. Requires 5-50μm filtered air and ISO VG32 hydraulic oil lubrication (optional).
- Vertical load safety brakes in automated assembly lines
- Position holding in CNC rotary index tables
- Emergency stop systems for material handling robots
- Precision fixturing in semiconductor wafer processing
- Overhead crane brake mechanisms
Installation notes:
- Align lock unit within 0.2mm perpendicular tolerance
- Maintain 0.5-1mm gap between lock and stopper plate
- Use anti-vibration washers in high-cycle applications (>5Hz)
- Max side load: 150N at cylinder tip
- Lock engagement time: 0.3s (at 0.5MPa)
- Do NOT use with impact loads exceeding 3,000N·s
| Property | Property Value |
|---|---|
| sku | SCLB40X125-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 125mm |
| Lock Position | Rear Cover with Lock Type |
