Airtac SCLB Rear Lock-Type Cylinder SCLB40X300-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB40X300-S Locking Cylinder Specifications
- Model: SCLB40X300-S
- Type: Double-acting cylinder with mechanical locking
- Bore size: 40mm
- Stroke: 300mm
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Locking force: 1,960N (at 0.5 MPa)
- Locking method: Wedge-type mechanical lock
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Mounting type: Standard ISO 15552 foot mounting (alternative options available)
- Port size: G1/8 (NPT1/8 optional)
- Material: Aluminum alloy barrel, hardened steel piston rod
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP67 (rod extended), IP65 (retracted)
- Weight: 3.5kg (7.7 lbs)
- Dimensions: 450mm(L) × 82mm(W) × 82mm(H)
- Lubrication: Pre-lubricated (recommended relubrication every 3,000km stroke)
High-precision locking cylinder with fail-safe mechanical brake mechanism, designed for vertical applications requiring position retention during power/pressure loss. Features triple sealing structure with wear-resistant guide bands and integrated magnetic sensor slots (sensors optional). Requires 40μm filtered air with ISO VG32-grade lubricant.
- Vertical lifting mechanisms in assembly lines
- Safety positioning in press brake machines
- Workpiece clamping in CNC machining centers
- Emergency stop systems for material handling
- Semiconductor equipment requiring vibration-free holds
Installation note:
Locking function activates automatically at stroke ends. For mid-stroke locking,
specify "-SM" variant. Maintain 0.3 MPa minimum pressure for reliable unlocking.
Lubricate piston rod weekly in high-cycle applications.
Critical notice:
Never apply external force to release locked piston - use manual release valve.
Avoid lateral loads exceeding 50N. Align cylinder within ±1° angular tolerance.
| Property | Property Value |
|---|---|
| sku | SCLB40X300-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 300mm |
| Lock Position | Rear Cover with Lock Type |
