Airtac SCLB Rear Lock-Type Cylinder SCLB40X50
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB40X50 Locking Cylinder Specifications
- Model: SCLB40X50
- Type: Double-acting pneumatic cylinder with mechanical locking
- Bore size: 40 mm
- Stroke: 50 mm
- Operating pressure: 0.1–0.9 MPa
- Operating medium: Clean dry air (40μm filtered)
- Temperature range: -20℃ to 80℃
- Buffer type: Adjustable pneumatic cushion
- Locking mechanism: Spring-assisted mechanical lock (manual release optional)
- Mounting style: ISO 15552 standard mounts
- Cylinder material: Anodized aluminum alloy
- Rod material: Hard-chromed stainless steel (SUS304)
- Seal material: High-wear resistance NBR rubber
- Weight: ~2.7 kg
- Dimensions: 178mm(L) × 68mm(W) × 68mm(H) (excluding mounting accessories)
- Protection rating: IP67 (rod extended)
- Piston speed: 50–800 mm/s
- Cushion adjustment: 5mm adjustable range
Heavy-duty locking cylinder designed for position retention during power loss or emergency stops. Features dual-position locking capability with zero backdrive, making it ideal for vertical load applications. The chrome-plated rod and multi-lip seals ensure minimal leakage even under side load conditions.
- Automated assembly line clamping fixtures
- Overhead load safety brakes in material handling
- Precision positioning in semiconductor equipment
- Elevator emergency stop systems
- Robotic welding position locking
Installation note:
Locking mechanism engages at ±3mm from stroke ends. For vertical use,
install with rod facing downward. Lubricate with ISO VG32 hydraulic oil
monthly. Avoid side loads exceeding 10% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | SCLB40X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <50mm> |
| Lock Position | Rear Cover with Lock Type |
