Airtac SCLB Rear Lock-Type Cylinder SCLB40X50-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB40X50-S Locking Cylinder Specifications
- Model: SCLB40X50-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: 40mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Locking force: 1,570N (at 0.5MPa)
- Lock release pressure: ≥0.15MPa
- Cushioning type: Adjustable rubber buffer (both ends)
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 adapter optional)
- Mounting type: Basic (axial foot & front flange)
- Rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 1.45kg ±2%
- Dimensions: 150mm(L) × 52mm(W) × 52mm(H)
- Protection rating: IP54 (standard), IP67 (optional w/rod cover)
High-precision locking cylinder featuring dual safety mechanisms: mechanical position lock and pneumatic safety circuit. The SCLB series incorporates a spring-engaged wedge locking system that activates automatically during pressure loss, making it ideal for vertical load holding. Requires 5μm filtered air and ISO VG32 hydraulic oil lubrication for optimal performance.
- Vertical lift emergency braking in material handling
- Position retention in CNC rotary index tables
- Overhead load locking in automotive assembly lines
- Safety stops in injection molding ejector systems
- Precision fixturing for optical component manufacturing
Installation note:
Locking mechanism requires manual release via maintenance port (M3) during initial setup.
Maintain ≥20mm clearance around locking unit for thermal expansion. Lubricate guide shafts
monthly with ISO VG32 oil. Avoid side-load forces exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SCLB40X50-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <50mm> |
| Lock Position | Rear Cover with Lock Type |
