Airtac SCLB Rear Lock-Type Cylinder SCLB40X500
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB40X500 Locking Cylinder Specifications
- Model: SCLB40X500
- Type: Double-acting cylinder with manual mechanical locking
- Bore size: 40mm
- Stroke: 500mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Locking force: 1,200N (max)
- Mounting type: Basic/Foot-mounted (ISO 15552 standard)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: ~3.8kg (excluding accessories)
- Dimensions: 600mm(L) × 80mm(W) × 80mm(H) (full extension)
- Port size: M5x0.8 (standard), G1/8 optional
- Position detection: Magnet compatible (sensor not included)
Heavy-duty locking cylinder designed for position retention in vertical/horizontal applications. Features dual-stage locking mechanism with fail-safe manual override. The chrome-plated piston rod and corrosion-resistant construction ensure durability in humid or mildly corrosive environments. Requires 5μm filtered air with ISO 8573-1:2010 class 4.2.3 air quality.
- Injection molding machine clamp positioning
- Automated assembly line safety interlocks
- Material handling vertical lift brakes
- Press tooling with mid-stroke hold requirements
- Robotic welding fixture stabilization
Installation note:
Engage locking mechanism only when cylinder is fully stopped.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil.
Avoid side loads exceeding 50N during operation.
| Property | Property Value |
|---|---|
| sku | SCLB40X500 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 500mm |
| Lock Position | Rear Cover with Lock Type |
